Vertical Form Fill Seal Machine
Vertical Form Fill Seal Machine, DC-890A
  • Standard safety door (for safety production)
  • Alignment tool
  • Feeding device
  • Longitudinal sealing roller (heat sealing)

Vertical Form Fill Seal Machine, DC-890A

Automatic VFFS single-lane machine for back seal stick pack packaging
  • Bag width

    11-45mm (non-adjustable once selected)

  • Bag length

    30-180mm (adjustable)

  • Packing speed

    30-50 bags/min

DC-890A automatic single-lane VFFS packaging machine is ideal for back seal stick packaging of liquids, powders, particles, and other products in the food, medicine, and daily chemical industries. The vertical form fill seal machine offers simple, user-friendly operation; users only need to input the values in the system to adjust sachet lengths, production time and store product parameters. It's the perfect solution for customers with high production capacity and speed, as well as those needing back seal packing.

Request a Quote
Specifications
Bag width 11-45mm (non-adjustable once selected)
Bag length 30-180mm (adjustable)
Filling volume 1-40ml
Packing speed 30-50 bags/min
Power supply 220V, 50Hz, 3.5kW
Air consumption 0.2L/min
Machine weight 350kg
Features
  • Vertical Form Fill Seal Machine, DC-890A
    When feeding, the material is swiftly acquired, preventing any droplets from causing a leak due to clamping the bag. Additionally, the horizontal pressure from sealing is even, meaning that whether you start from the middle or both ends of the bag, the lines will be consistent and the seal will be tight.
  • Vertical Form Fill Seal Machine, DC-890A
    Film rolling and running helps maintain the tension of the film, resulting in a flat and unwrinkled bag.
  • Vertical Form Fill Seal Machine, DC-890A
    The advanced rigid balance technology plus synchronous gear structure of transverse sealing ensures an even and effortless seal with uniform pressure.
  • Vertical Form Fill Seal Machine, DC-890A
    This mold is constructed with imported mold knives, meticulously polished through 12 steps to provide a neat, continuous surface and a smooth, burs-free edge.
  • This mold is constructed with imported mold knives, meticulously polished through 12 steps to provide a neat, continuous surface and a smooth, burs-free edge.
  • Two cooling systems are in place, guaranteeing a smooth bag incision without any burrs and providing optimal protection for the cutter.
  • Panasonic servo motor is a great feature of this sealing machine, making adjustments and corrections swift and easy. It offers convenient, speedy changes to film rolling and effectively corrects any deviations.
Details
  • Standard safety door (for safety production)Standard safety door (for safety production)
  • Alignment toolAlignment tool
  • Feeding deviceFeeding device
  • Longitudinal sealing roller (heat sealing)Longitudinal sealing roller (heat sealing)
  • PLC operation interface and temperature control tablePLC operation interface and temperature control table
  • Easy-tear seal cutterEasy-tear seal cutter
Related Products

About Dachuan

Established in 1998, Shantou Dachuan Machines Co., Ltd. is dedicated to creating automated and intelligent packaging solutions for manufacturers around the world. We offer a selection of packaging machines that boast high-performance, quality engineering and excellent craftsmanship.
